Polyethylene Film Paper Aluminum Foil Rotogravure Intaglio Printing for food plastic printing High speed
rotogravure printing production line.pdf
| Color quantity | 10 |
| Max. Width of printing | 1000mm |
| Mechanical speed | 180m/min |
| Printing speed | 150m/min (Variable because of different ink, film, familiarity of operator) |
| Length of printing cylinder | 480~1000mm |
| Dia. of printing cylinder | Φ120mm~Φ320mm |
| Color control precision | ±0.12mm (Variable because of different ink, film, familiarity of operator) |
| Max. unwind/rewind Dia.: | Φ600mm |
| Tension range | 3~50kgf |
| Tension control precision | ±0.5kgf |
| Core, I.D. of raw material | Φ76mm |
| Pneumatic source | 0.6Mpa |
| Impression roller pressure | 370kgf |
| Doctor blade transverse move range | ±5mm |
| Drying mode | Electrical heating |
| Heating power | 18×10=180Kw |
| Mail motor | 15Kw |
| Power consumption | 231kW |
| Machine size | 16500×3550×2850(mm) |
| Machine weight | 26000kg |
| Automatic speed up/down to the target speed gradually |
| Max. speed limit can be set for different material or cylinder size |
| Idle or running status can be exchanged |
Structure
- Loading web mode: air shaft
- Independent driving control system: vector frequency conversion control system
- The opposite sensor couple automatic position the new reel for unwind
- Tension detect: displacement of dancing roller
- Closed loop tension control
- Pre-driving of waiting roller before roll exchange and splicing
- Auto position limit for unwind stand turning
Parameter
- magnetic powder clutch 2 set(made in WENZHOU)
- manual tension controller 1 ser (made in WENZHOU)
- Tension range 3~50kgf
- main low voltage apparatus China Zhengtai
video link of LC-E model rotogravure printing machine (Aluminum foil, paper, plastic film)
https://youtu.be/NPGk7K2FOhQ
video link about LC-E model rotogravure printing machine (Export to Pakistan, print aluminum foil, BOPP, PE, PVC, PET,Paper)
https://youtu.be/lZ8PziP51Xk
Example:
Q: what kind of pre-sale service do you offer? do you offer the free sample? and how about the freight cost?
A: we will make sample according to customer material by our machine, and take a video for customer reference. above is free, but the freight cost should be paid by customer.
Q: what kind of in-sale service do you offer? what is the warranty for the easy fault parts? and what is the delivery time for the machine?
A: if the easy fault parts is in the warranty period, we will offer the free replacement as per quality warrantee terms and conditions, and the delivery time for the machine is within 45 working days after the deposit
